ISO Standard High Strength and Wear Resistance Double Pitch Conveyor Chains
  • High Strength and Wear Resistance

  • Customization and OEM Available for Specific Application

  • Extensive Inventory of Spare Parts and Accessories

  • Well-Developed Worldwide Marketing Network

  • Efficient After-Sale Service System

Custom Conveyor Chain Min. Order: 100
  • DIN/ISO NO: Drawing or Sample

  • Pitch (mm): CUSTOM

  • Roller Diameter(mm): CUSTOM

  • Width Between Inner Plates (mm): CUSTOM

  • Pin Diameter(mm): CUSTOM

  • Plate Thickness (mm): CUSTOM

  • Average Tensile Strength: CUSTOM

  • Weight Per Meter (kgs/m): CUSTOM

  • Chain Size: 5F, 10F, 5Meters

  • Specification: Simples, Duplex, Triplex, Quadruplex

  • Material: 40Mn, 45Mn, Stainless Steel304

Conveyor Chains 81X Lumber Min. Order: 100
  • Model No.: 81X

  • Pitch (mm): 66.27

  • Roller Diameter(mm): 23.00

  • Width Between Inner Plates (mm): 27.00

  • Pin Diameter(mm): 11.10

  • Plate Thickness (mm): 4.00

  • Average Tensile Strength: 128.9KN

Lumber Conveyor Chains 81XH Min. Order: 100
  • Model No.: 81XH

  • Pitch (mm): 66.27

  • Roller Diameter(mm): 23.00

  • Width Between Inner Plates (mm): 27.00

  • Pin Diameter(mm): 11.10

  • Plate Thickness (mm): 7.94/5.55

  • Average Tensile Strength: 175.7KN

Lumber Conveyor Chains 81XHH Min. Order: 100
  • Model No.: 81XHH

  • Pitch (mm): 66.27

  • Roller Diameter(mm): 23.00

  • Width Between Inner Plates (mm): 27.00

  • Pin Diameter(mm): 11.10

  • Plate Thickness (mm): 7.94

  • Average Tensile Strength: 212.6KN

Lumber Conveyor Chains 81XHS Min. Order: 100
  • Model No.: 81XHS

  • Pitch (mm): 66.27

  • Roller Diameter(mm): 23.00

  • Width Between Inner Plates (mm): 27.00

  • Pin Diameter(mm): 11.10

  • Plate Thickness (mm): 7.60

  • Average Tensile Strength: 177.2KN

Lumber Conveyor Chains 500R Min. Order: 100
  • Model No.: 500R

  • Pitch (mm): 50.00

  • Roller Diameter(mm): 25.40

  • Width Between Inner Plates (mm): 25.40

  • Pin Diameter(mm): 14.63

  • Plate Thickness (mm): 5.00

  • Average Tensile Strength: 114.5KN

Lumber Conveyor Chains 441.100R Min. Order: 100
  • Model No.: 441.100R

  • Pitch (mm): 100.00

  • Roller Diameter(mm): 25.40

  • Width Between Inner Plates (mm): 25.40

  • Pin Diameter(mm): 14.63

  • Plate Thickness (mm): 5.00

  • Average Tensile Strength: 114.5KN
