08B-2 Sharp-Tooth Chain

What is a pointed-tooth chain?

A pointed-tooth chain is a specialized type of chain typically featuring chain plates with pointed-tooth structures, widely used in industrial applications.

Structural Features

Spiked chains are usually composed of chain links. Each link features outer plates at both ends, with inner plates attached to the inner walls of the outer plates. Pins are inserted between the outer and inner plates, with rollers mounted over the pins. Sleeves are fitted between the rollers and pins. The key feature is that the conveying edges of both outer and inner plates are formed into protruding and recessed spiked teeth.

Working Principle

Pointed tooth chains utilize ANSI/ISO standard roller chains that mesh with sprockets for transmission. The pointed teeth on the chain plates grip the material, enabling synchronized movement between the chain and the conveyed goods.

Application Fields

Pointed tooth chains are extensively used in the wood processing industry for gripping and conveying timber. They are also commonly employed in textile machinery and similar fields to transport strip-shaped items.

Advantages

The interlocking tooth design on the chain plates increases friction with conveyed materials, preventing slippage on the conveyor line. This ensures stable transport and enhances safety.

What is 08B Tooth Chain?

08B tooth chain is a common industrial chain based on the 08B roller chain, featuring added tooth structures on the chain plates.

Structural Features

Spiked teeth are machined onto the plates of standard 08B roller chains. The shape and dimensions of these teeth are engineered for specific applications to ensure effective material gripping or conveying.

Performance Advantages

The spiked teeth increase friction between the chain and conveyed materials, enabling more stable transport and preventing slippage. It retains the advantages of the 08B roller chain, including high strength, excellent wear resistance, and high transmission efficiency.

Application Areas

Commonly used in the wood processing industry, such as in wood slicers and wood conveyors, for gripping and transporting lumber. Additionally, it finds application in conveyor lines within the food, pharmaceutical, and packaging industries for transporting items with specific shapes or requiring precise positioning.
